TRIG
DESCRIPTIONS
TRIG is a DC source measurement unit with small size, text
FEATURES
Easy-to-use
Plug-and-play with built-in function modes can shorten the learning curve and simplify measuring processes, so you can focus on analyzing your data or solving problems.
Low Voltage & Current Measurement
Input/output voltage range from 5V to 1 mV; input current range from 15 mA to nA.
Experimental Monitoring
Real-time display your data on the screen and check your measurement anytime, anywhere with the remote accesses.
In-Situ & Portability
Wireless recording in closed chambers, glove boxes, incubators, or outdoor environments.
Standard package included :TRIG×1, alligator leads×1, USB power adaptor×1 & USB to typeC cable×1
Product Specification
![Elite-TRIG-t](https://www.elitedaq.com/wp-content/uploads/2023/10/Elite-TRIG-t.png)
Your Assistant for Multiple Devices Management
TRIG
TRIG capable of one trigger-input channel, two 5V switches, two isolated switches and four current regulators can help you coordinate your devices and system
-
1ch
trigger
input -
2ch
5V-output
switch -
2ch
isolated
switch -
4ch
current
regulator
-
Current Regulator
4 channels; 0-200mA (resolution 0.5 mA)
-
5V Output Switch
2 channels; 5V enable/disable
-
Isolated Switch
2 channels
-
Trigger Input
1 channels; triggered (activated) by input signals of rising edge, falling edge or both the rising and falling variant.
-
Time Resolution
~ 100 ms
-
Wireless Range
> 3 m
-
Dimension
Ø80 x 20 mm
-
Weight
55 g (1.94 oz)
